1000TPH Radial Telescopic Stacker for Coking Coal and Iron ore

This is portable radial telescopic stacker for handling coking coal and iron ore. And it will be mainly used in indoor material yards facing high dust, humidity and corrosive environments.

This is a wheel travel radial telescopic conveyor for a power plant.

Specification

• Stacking Capacity: 800-1000 tons/hour
• Stack height: 7-10 meters.
• Conveying Length: Full working length 40 meters, from the pile to the large belt or across the material yard.
• Telescopic Structure: Applying telescopic structure to cover blind areas and flexible operation in multiple material yards.
• Conveyor Belt: 1200*6（6mm+1.5mm）
• Conveyor Drive Pulley: 630mm, 12mm rubber lagged. You can find more conveyor pulleys from us.
• Conveyor Roller: Diameter 108mm steel conveyor roller sets.
• Belt Width: 1200 mm, the conveyor belt upgrade is available.
• Outer Conveyor: 30 m.
• Inner Conveyor: 10 m.
• Conveyor Drive: Using motor and gear box to drive conveyor belt.
• Conveyor Power: ≥60Kw.
• Moving Method: Electric energy drives the tire to walk, the front end of the equipment can achieve radial moving.
• Moving Unit Power: ≥16Kw.
• Hydraulic Lifting: ≥22Kw.
• Telescopic Driver: 5.5kw.
• Standard Cables: 50m.

The outline dimension of this 1000tph radial stacker.

Features

• Flexible adjustment of the material stacking height (7-10 meters) and angle to achieve transfer from the stockpile area to the blind area (such as the dead corner at the edge of the stockpile).
• The telescopic arm design can cover a 40-meter operating radius, meet the needs of long-distance transfer, and realize ore transfer between two material yards.
• Set up a receiving bin with a buffer structure at the bottom. The width of the receiving bin must meet the three-sided feeding of the forklift.
• The high-power drive system meets the large processing capacity (1000 tons/hour).
• Two funnels are required, one at the tail of the mobile trolley and the other on the stacker-reclaimer track. It has the function of moving and self-locking, and can be directly connected to the large belt system of the stacker-reclaimer to achieve continuous feeding. The funnel needs to be affixed with a stainless steel lining greater than 10mm to keep it wear-resistant, smooth and non-blocking.

We provide radial telescopic stacker design service for your project.

Applications

This portable radial telescopic stacker is used in handling bulk materials like:

• coking coal
• iron ore
• other materials

If you need a radial stacker for stakcing bulk materials, please contact me.
